Adjusting the Color Tuner Settings
The Color Tuner settings allow you to adjust the color management system, 2 point
white balance, 11 point white balance, turn color channels o for testing, and display
SMPTE, at, ramp, and uniformity analyzer test patterns.
To access the color tuner table:
Menu > Picture > Color Calibration > Color Tuner
To turn color channels o and on:
1. Use the Arrow buttons on the remote to highlight Red, Green, or Blue.
2. Press the OK button to turn the color channel o or on. An X appears over a
color channel that has been turned o.
3. Only two color channels can be turned o at the same time.
To show or hide the SMPTE Test Pattern:
Menu > Picture > Color Calibration > Color Tuner > SMPTE Test Pattern
1. Use the Arrow buttons on the remote to highlight O. Use the Left/Right
Arrow buttons to select On to show the SMPTE Pattern.
—or—
2. To hide the SMPTE Test Pattern, use the Left/Right Arrow buttons to
select O.
SMPT Test Pattern
O
To adjust the color management system/2 point white balance settings:
1. Use the Arrow buttons on the remote to highlight the Hue, Saturation,
Brightness, Oset, or Gain of the color you wish to adjust. Press the OK button.
2. Use the Left/Right Arrow buttons to adjust the value. When you are nished
press the OK button to save the setting.
To adjust the 11 Point White Balance settings:
1. From the Color Tuner table, use the Arrow buttons to highlight the top bar and
then press the Left/Right Arrow buttons until the 11 POINT WHITE BALANCE
menu is displayed.
2. Use the Arrow buttons on the remote to highlight the Gain and Color values
you wish to adjust. Press the OK button and use the Left/Right Arrow buttons
to adjust the value. When you are nished, press the OK button to save the
setting.
11 Point White Balance
Gain Red Green Blue
5% 0 0 0
Color Tuner
Red Green Blue Cyan Magenta Yellow
Hue 0 0 0 0 25 -14
Saturation -1 5 -4 0 -2 0
Brightness -24 0 -22 0 0 0
Oset 0 0 0
Gain 0 0 0
WARNING: The Color Tuner, 11 Point White Balance, and test
patterns allow technicians to manually calibrate the TV. Calibration
requires specialized training, an input with precisely set colors, and
a specialized light meter.
TIP: Any changes made aect the color temperature setting. Select
the preferred color temperature setting rst. See Adjusting the
Color Temperature on page 16.

Vizio V656-G4 Specifications

General

Screen Type	led
Wall Mount	400mm x 200mm
Features	quantum color, 12 local dimming zones, smartcast, apple airplay, chromecast built-in, works with siri, google assistant, alexa
Tuner	digital
Screen Size	64.5 inches, 65 inches
Resolution	4k (2160p)
Refresh Rate	60hz
HDR	yes
HDR Format	dolby vision, hdr 10, hybrid log-gamma (hlg)
Built-In Speakers	yes
Speakers Output	16 watts
HDMI ARC Ports	yes
USB Ports	1
USB 2.0 Ports	1
Ethernet	yes
RF Antenna	yes
Bluetooth	no
Network	built-in wi-fi, ethernet
Digital Optical Audio Outputs	1
Analog Audio Outputs	1
Component Video Inputs	0
Composite Video Inputs	1
DVI	0
SmartTV	smartcast
Smart Applications	amazon alexa, apple homekit, google assistant, siri
Voice Assistant	no
Remote Control	standard
3D	no
Power Consumption	269 kilowatt hours
Depth with Stand	11 inches
Height with Stand	36.1 inches
Width with Stand	57.7 inches
Net Weight with Stand	43 pounds
Depth without Stand	3.1 inches
Height without Stand	33.5 inches
Net Weight without Stand	41.9 pounds
