Front Panel
1. INPUT: Audio Cable Jack Connections
2. OUTPUT: Audio Cable Jack Connections
3. GAIN: Input Signal Adjustment Knob
4. BASS BOOST: Bass Adjustment Knob
5. LPF: Low Frequency Filter Adjustment Knob
6. FLT: Bypass Crossover Selection
7. HPF: High Frequency Filter Adjustment Knob
8. LED: Power Status LED
FUNCTIONS
Rear Panel
9. POWER INPUT: Power Cable Terminal
10. FUSE: In-Line Protection Fuse(s)
11. SPEAKER OUTPUT: Speaker Wire Terminal
1
2
3 4 5
6 7
9
10 11
8
SRA500.2
Shown
SRA500.2
Shown
