15 16
CONTROLS
Subwooer Bridge Wiring
Connect the subwoofers positive + terminal to the
positive + terminal of the left channel, then connect the
negative (-) terminal of the subwoofer to the negative
(-) terminal of the amplier’s right channel.
80 Hz
Amplier Crossover Settings
LPF
Description
Gain: This feature controls the audio input
signal strength going into the amplier.
Bass Boost: Increases the bass level from
+1dB up to +18dB.
LPF: Low pass lter that reduces the signal
level of frequencies above the bass region.
FLT: Crossover setting that disables and
bypasses the internal crossover.
HPF: High pass lter that reduces the signal
level of frequencies below the bass region.
LPF Frequency: Low pass crossover
frequency lter adjustment.
HPF Frequency: High pass crossover
frequency lter adjustment.
Power LED: Power and protection amplier
status indicator.
Input: Line level audio inputs.
Output: Line level audio outputs.
4Ω
SPEAKER
IMPEDANCE
SPEAKER WIRING Continued...
