Reference Manual
Features
Rugged, touring grade chassis. E.I.A. Standard 19" (48.3cm) rack-mountable.
Three output channels. Two stereo channels for Hi output and one summed mono Sub channel.
Front panel power switch with soft start for loudspeaker protection.
Built in Hi and Lo pass electronic crossovers.
Anti Clip limit protection prevents harmful signals from damaging loudspeakers.
High damping factor provides greater control over low frequency drivers for a clean, accurate low end.
Balanced jack/XLR inputs with balanced direct XLR outputs.
Complete protection against shorted outputs, mismatched loads, overheating and DC input/output.
Efficient heat sinks and self-contained forced air cooling system.
Three year warranty and guarantee.
Precautions
Although your amplifier is protected from external faults, the following safety precautions are recommended:
1. There are important differences between the CH 1&2 Hi outputs and the Sub&Hi outputs. Do not connect
B12 cabinets directly to the Sub&Hi outputs. Connect B12 cabinets to the CH 1&2 Hi outputs using the
B12's top input speakon, or the link out Speakon on B15 Sub cabinets to the B12's lower input speakon.
B15 Subs must be connected to the Sub&Hi outputs with 4 core cable for the B12's to operate.
2. Switch off the amplifier or turn down the inputs before connecting to the in/out XLR's.
3. Do not short the ground lead of an output cable to the input signal ground. This will form a ground loop
and may cause oscillations.
4. Do not operate the amplifier from AC mains in excess of 10% variation above or below the selected line
voltage, and only at the specified line frequency.
