Linea HE
THINGS YOU SHOULD KNOW
1.1 GAS APPLIANCE
Gas Safety (Installations and Use) Regulations.
In the interests of your safety and that of others it
is a legal requirement that all gas appliances are
installed and correctly maintained by a competent
person and in accordance with the latest regula-
tions.
1.2 ELECTRICAL SUPPLY
Please ensure that this appliance has been prop-
erly connected to the electrical supply by means
of a double pole isolator or un-switched socket,
and that the correct size of fuse (3 AMP) has been
fitted.
Warning: this appliance must be earthed!
1.3 GUARANTEE REGISTRATION CARD
Please take the time to fill out your guarantee
registration card. The completed warranty card
should be posted within 30 days of installation.
1.4
BENCHMARK
LOG BOOK
The
Benchmark
Log Book is supplied with your
boiler. This important document must be com-
pleted during the installation/commissioning of
your boiler. All CORGI Registered Installers carry
a CORGI ID card and have a registration number.
Both should be recorded in your
Benchmark
Log
Book. You can check your installer by calling
CORGI direct on 01256 372300. Failure to install
and commision the appliance in accordance with
the manufacturers instructions may invalidate the
warranty. This does not affect your statutory
rights.
1.5 HOW DOES IT WORK?
Your Linea HE boiler is a high efficiency combina-
tion boiler, which supplies heated water to your
radiators and hot water to your taps.
The central heating is controlled via a time clock
and/or any thermostats that your installer may
have fitted. The boiler will light when a hot water
outlet (a tap) is opened. The boiler may also
function periodically to pre-heat the hot water heat
exchanger. The Linea HE boiler lights electroni-
cally and does not have a pilot light. In the unlikely
event of a fault developing with your boiler, the
supply of gas to the burner will be terminated
automatically.
1.6 DIMENSIONS
HEIGHT
WIDTH
DEPTH
845 mm
453 mm
390 mm
1.7 CLEARANCES REQUIRED
ABOVE
BELOW
SIDES
FRONT
150 mm
120 mm
12 mm
600 mm
1.8 FROST PROTECTION SYSTEM
The Linea HE is equipped with a built-in frost
protection system, this enables the boiler to over-
ride the time controls – if switched off – and
operate the burner and/or pump, should the tem-
perature drop below 6 °C.
Please note that the frost protection system is
designed to protect the appliance only, should
frost protection be required for the central heating
system, additional controls may be required.
NOTE
The frost protection system is reliant on the ap-
pliance having a permanent electrical supply, and
being in a non-fault condition.
1.9 ADDITIONAL CONTROLS
Additional controls such as an external tempera-
ture sensor kit or under floor heating safety ther-
mostat are available as optional accessories for
this appliance. You should consult your installer
and/or the supplementary instructions supplied,
on their use (if installed).
