4.19 Haldex coupling (Jetta 4motion):
Change oil
Note
♦ On vehicles with Haldex coupling the drain plugs and sealing
plugs of both systems are often interchanged, due to the in‐
tegrated housing construction of Haldex coupling and final
drive. Caution must be exercised during maintenance and
servicing, as incorrect fitting can cause the Haldex coupling
and the final drive to fail.
♦ The Haldex coupling and the final drive are one system with
separate oil systems.
♦ -1- Plug for Haldex oil filler hole.
♦ -2- Drain plug for Haldex oil.
♦ -3- Plug for gear oil filler hole.
♦ -4- Drain plug for gear oil.
Special tools and workshop equipment required
♦ Torque wrench -V.A.G 1331-
♦ Used oil collection and extraction unit -V.A.G 1782-
♦ Oil spill cloth -VAS 6204/1-
Golf Variant 2007 ➤ , Golf Variant 2010 ➤ , Jetta 2005 ➤
Maintenance - Edition 09.2009
78 4. Descriptions of work
