Manual Trans. –
02Q
VW Golf & GTI Quick Reference Specication Book • September 2012 121
Clutch – 02Q
Fastener Tightening Speciîš¿cations
Component Fastener
size
Nm
Clutch pedal mounting bracket-to-cross
panel nut
1)
- 25
Clutch pedal-to-mounting bracket through
bolt nut
1)
- 25
Impact bolster support to steering column bracket bolt
1)
- Secured with one bolt - 20
- Secured with two bolts - 10
Pressure plate-to-dual mass ywheel bolt
2)
M6 13
M7 20
Slave cylinder with release bearing-to-transmission bolt
1)
- Slave cylinder with metal housing (without
locking uid)
- 12
- Slave cylinder with plastic housing (with
locking uid)
- 15
1)
Replace fastener(s).
2)
Carefully tighten diagonally and in small stages so that the slave cylinder bolt tabs
do not break off.
3)
Loosen and tighten in small steps and in a diagonal sequence.
