170 VW Golf & GTI Quick Reference Specication Book • September 2012
Interior Trim Fastener Tightening Speciîš¿cations
Component Nm
Airbag emblem screw
- Screw 4
- Nut 1.5
Ashtray control module 9
Ashtray screw 1.5
Backrest adjuster screw 2.5
Bracket for front seat support and operating lever 3.5
Bracket seat pan 2.4
Drive side footwell cover screw 1.5
Drive side left trim screw 1.5
Drive side right trim screw 1.5
Front door trim panel screw 4.5
Front seat support
Footwell trim screw 1.5
Lock carrier cover screw 1.5
Lower B-pillar trim screw 4
Luggage compartment trim screw 8
Pull support cover 1.5
Rear door trim screw 4.5
Seat backrest 34.5
Storage compartment instrument panel (center) screw 1.5
Storage unit-to-center armrest screw 9
Upper A-pillar trim screw 4
Upper B-pillar trim screw 4
1)
For bolt tightening clariîš¿cation, refer to ElsaWeb, Interior Trim.
Seat Frames Fastener Tightening Speciîš¿cations
Component Nm
Backrest bolts 34.5
Front seat frame bolts 40
Rear belt buckle bolt 40
Rear seat center backrest clamp bolt 9
Seat drawer mount bolts 2
Seat frame bracket bolts 3.5
Seat support bracket bolts 3.5
Side upholstery bolts 8
