4.8.5 Tyre pressures ID.4
Note
♦
During delivery inspection, check that tyre inflation pressure
sticker is fitted. If the sticker is missing, order a new sticker
through ETKA.
♦
The mandatory tyre pressures for the respective model can
be found on a sticker attached to the inside of the tank flap
or to the B-pillar.
♦
If the inflation pressure sticker is missing, proceed as fol‐
lows:
♦
Locate correct part number for respective vehicle in ETKA.
♦
Using part number, determine respective inflation pressures
in tyre inflation table.
♦
Uniform pressure: if tyre sizes are not shown for a part num‐
ber, then a uniform pressure is valid for all authorised wheel/
tyre combinations. ⇒ Wheels and tyres guide; Rep. gr. 44;
Wheels, tyres, vehicle geometry; Wheel and tyre combina‐
tions
Check tyre pressure using tyre inflator -VAS 5216-, correct if
necessary.
Part number -11A 010 000- ID.4
Half payload
kPa/bar/psi
Half load, comfort
kPa/bar/psi
Full payload
kPa/bar/psi
Tyre size Front Rear Front Rear Front Rear
235/60 R18 250/2.5/36 250/2.5/36 --- --- 270/2.7/39 290/2.9/42
235/55 R19 250/2.5/36 250/2.5/36 --- --- 250/2.5/36 280/2.8/41
235/50 R20 250/2.5/36 250/2.5/36 --- --- 250/2.5/36 280/2.8/41
235/45 R21 250/2.5/36 250/2.5/36 --- --- 250/2.5/36 280/2.8/41
Part number
-11A 010 000 G-
ID.4
Half payload
kPa/bar/psi
Half load, comfort
kPa/bar/psi
Full payload
kPa/bar/psi
Tyre size Front Rear Front Rear Front Rear
235/55 R19 250/2.5/36 250/2.5/36 --- --- 250/2.5/36 290/2.9/42
235/50 R20 250/2.5/36 250/2.5/36 --- --- 250/2.5/36 290/2.9/42
235/45 R21 250/2.5/36 250/2.5/36 --- --- 250/2.5/36 290/2.9/42
Part number
-11A 010 000 G-
ID.4
Half payload
kPa/bar/psi
Half load, comfort
kPa/bar/psi
Full payload
kPa/bar/psi
Tyre size Front Rear Front Rear Front Rear
235/55 R19 250/2.5/36 --- --- --- 250/2.5/36 ---
255/50 R19 --- 250/2.5/36 --- --- --- 290/2.9/42
ID.4 2021 ➤
Maintenance - Edition 12.2020
4. Descriptions of work 29
