46-30
14 - Outer wheel bearing
15 - Hex nut
Adjusting wheel
bearing play
Using a screwdriver it
must be possible to
move the thrust
washer by finger
pressure (without
leverage) Page 42-
20
Secure with locking
ring and new cotter pin
16 - Cotter pin
Always replace
17 - Grease cap
Removing and
installing Page 42-
29
18 - Lock ring
19 - Thrust washer
20 - Wheel bolt, 110 Nm (81
ft lb)
Page
4
of
10
Rear wheel brakes, servicing (disc brakes)
12/7/2004
