4.54 Clock and date: setting
Setting time and date in Infotainment system
Switch on ignition.
Switch on Infotainment system.
Press Infotainment button CAR .
Press Setup function button.
Press Time and date function button.
Press Time function button and set current time.
Press Date function button and set current date.
4.55 Underbody: inspecting for damage to
underbody sealant, underbody panels,
routing of lines, plugs
Caution
During inspection, also check floor pan, wheel housings
and sills.
Always ensure that all lines are secured in their mount‐
ings,
that all plugs are available and that there is no visible
damage on the underbody.
Faults found must always be rectified (repair measure).
This inhibits corrosion and rusting through.
4.56 Toothed belt (petrol engines): renewing
Camshaft drive toothed belt (petrol engines): renewing
⇒ page 119
Coolant pump toothed belt (petrol engines): renewing
⇒ page 119
4.56.1 Camshaft drive toothed belt (petrol en‐
gines): renewing
Description of work
4-cylinder injection engine (1.4 l direct injection engine, tur‐
bocharger); Rep. gr. 15 ; Toothed belt drive; Removing and
installing toothed belt
4.56.2 Coolant pump toothed belt (petrol en‐
gines): renewing
Description of work
⇒ 4-cyl. injection engine (1.4 l direct injection engine, turbo‐
charger); Rep. gr. 19 ; Coolant pump/thermostat assembly
4.57 Camshaft drive toothed belt: renewing
(diesel engines)
TDI common rail engines:
⇒ Rep. gr. 15 ; Toothed belt drive; Removing and installing
toothed belt
Tiguan 2016 ➤ , Tiguan RUS 2017 ➤
Maintenance - Edition 08.2017
