– If both spray fields are not at same height, adjust spray direc‐
tion upwards or downwards as follows:
– Adjust the spray jet -3- by turning the adjuster -2- using a Torx
screwdriver.
Washer jet adjustment for rear window wash system:
– If both spray fields are not at same height, adjust spray direc‐
tion of the two jets upwards or downwards as follows:
– Adjust spray jets using adjusting tool -T10127- or adjusting
tool -T40187- so that the water jet sprays onto the rear window
as shown.
4.39.3 Headlight washer system: Checking
spray jet settings
Jet adjustment dimensions for the right-hand headlight (left-hand
mirror image).
Checking jet setting
– Switch dipped beam on.
– Operate windscreen washer system.
The headlights are washed if the windscreen wiper lever is hold
in „Wipe position“ for at least 1.5 second.
The washer jet must spray to centre of headlights, see -B- and
-C-.
If spray pattern deviates from specifications, carry out repair
measures.
4.40 Wiper blade protection: Remove
Note
There are 3 different versions of wiper blade protection:
Touareg 2010 ➤
Maintenance - Edition 11.2011
4. Descriptions of work 107
