– Mark position of wheel relative to brake disc.
– Unbolt wheel bolts and remove wheel.
– Measure thickness of inner and outer pads.
a - Pad thickness without backplate
Wear limit: 2 mm
The brake pads have reached their wear limit at a pad thickness
of 2 mm (without backplate) and must be renewed (repair meas‐
ure). Inform customer!
Note
♦ When replacing brake pads, always check brake discs as well
for wear!
♦ Checking and, if necessary, replacing the brake discs is a re‐
pair measure.
– Check brake disc for wear. ⇒ Brake system ⇒ Rep. gr. 46 ⇒
Repairing front brakes
– Install wheel in marked position.
– Tighten wheel bolts diagonally to following torque setting:
⇒ page 76
– Place adapter in vehicle tool kit after completing work.
– Fit wheel bolt covers if necessary .
4.10.2 Rear disc brake pads: Checking thick‐
ness
– Illuminate area behind hole in wheel using an electric hand
torch.
– Determine thickness of outer pad by checking visually.
– Illuminate inner pad with an electric hand torch and mirror.
– Determine thickness of inner pad by checking visually.
a - Inner and outer pad thickness without backplate
Wear limit: 2 mm
The brake pads have reached their wear limit at a pad thickness
of 2 mm (without backplate) and must be renewed (repair meas‐
ure). Inform customer!
Note
♦ When replacing brake pads, always check brake discs as well
for wear!
♦ Checking and, if necessary, replacing the brake discs is a re‐
pair measure.
– Check brake disc for wear. ⇒ Brake system ⇒ Rep. gr. 46 ⇒
Repairing rear brakes
4.10.3 Condition of brake discs: Check
Check all brake discs for the following damage pattern:
Touareg 2010 ➤
Maintenance - Edition 11.2011
4. Descriptions of work 37
