2 Child seat anchors
WARNING
If the vehicle has been converted by ABT e-Line, it is possible
that the repair instructions provided below are no longer valid.
• In this case, please always refer to the repair instructions
from ABT e-Line, available in ElsaPro in the tab “Super‐
structures and modifications”.
⇒ “2.1 Assembly overview - front child seat anchors, Multivan/
Business”, page 142
⇒ “2.2 Assembly overview - rear child seat anchors”, page 143
2.1 Assembly overview - front child seat anchors, Multivan/Business
Note
♦
Removal and installation are described for the Top Tether retaining ring for individual seats. Removal and
installation for the 3-seat bench seat are analogous.
♦
Refer to the respective operating manual when installing the Top Tether retaining rings for the various seat
versions.
Transporter 2016 ➤
General body repairs, interior - Edition 03.2020
142 Rep. gr.69 - Passenger protection
