– Pull out spreader rivets -3- (qty. 11).
– Detach trim -1- in upper area.
– Press down retaining hooks of trim panel -arrow-, and remove
trim panel from trim.
– Guide seat belt through trim.
Installing
Install in reverse order of removal, observing the following:
Note
Before installing, check spreader rivets -3- for damage and renew
as necessary.
6.6 Removing and installing luggage com‐
partment floor
⇒ “6.6.1 Removing and installing luggage compartment floor,
wood-type, panel van”, page 264
6.6.1 Removing and installing luggage com‐
partment floor, wood-type, panel van
Removing
Transporter 2016 ➤
General body repairs, interior - Edition 03.2020
264 Rep. gr.70 - Trim, insulation
