Package Contents
Product Dimensions
A. (1) Tube
B. (1) Brass Grate with Lens
C. (1) Lamp Holder
D. (1) “U” bracket
customersupport@voltlighting.com • 813.978.3700
6.5”
5.5”
1” 1”
2”
9”
E. (1) PAR 36 Lamp
F. (2) Screws
G. (2) Nuts
Install Tube
1
Dig a 6.5”Diameter, 8” Depth hole on
the ground. Race supply wires into
the drilled hole. Place 2” of gravel in
bottom of hole for proper drainage.
Place tube inside of the hole and add
additional gravel around tube sides.
Supply Wire
Tube
Gravel
Soil
To Next Page
