8
9. Parallel Cable Connection
Parallel cable includes parallel communication cable and current sharing cable. Please follow below chart to
connect to the inverter.
9-1. Parallel Operation in Single phase
Two inverters in parallel:
Three inverters in parallel:
Four inverters in parallel:
9-2. Support 3-phase equipment
Follow below chart to connect inverters to support 3-phase equipment.
