6. OPERATING ELEMENTS
a) Meter
1 Display
2 Operating keys
3 Rechargeable battery compartment cover
4 Measuring button
5 Camera lens cover
6 Optical camera
7 Thermal imaging camera
8 Micro-USB socket
9 Micro-SD card slot
10 Rechargeable battery compartment
b) Operating Buttons
a
b
e
c
d
f
a ▲ Up button
b Menu / on-off button
c ◄ Left button
d ▼ Down button
e ► Right button
f “Enter”-button
