PM100 / 300 U

SER

ANUAL

ETTING

TARTED

VPN 98-052 P

AGE

Four further types of measurement are available. These are associated with

only specific basic measurements. Attempting to show ‘VA’ ‘PEAK’ for

example will result in a parameter error.

PEAK Peak value of the waveform V pk, A pk.

Display of crest factor may be selected in menu 4. Select V cf, A cf by using

the [V] and [A] keys in [PEAK] mode. Press [PEAK] again to cancel.

Press [MENU]

SELECT MENU

M[0] Outputs

Press [4] or [>] until you see the following display;

SELECT MENU

M[4] Key Options

Press [

↵

] until you see the following display;

PEAK

>pk< cf

Press [<] and [>] to make your selection

PEAK

pk >cf<

Press [↵] to move to the next item in the menu system,

or, press [MENU] to exit the menu system and return to the measurement

display.

HARM Displays either Voltage (Vhxx), Current (Ahxx), or Power (Whxx)

harmonics by pressing the [V], [A], or [W] keys.

Press [HARM] again to cancel harmonic display.

PM100

AH01 AH03

1st, 3rd current harmonic

2.47 0.526

Amplitude of harmonics in Amps

-015.1° -160.8° Phase of harmonic relative to VH01
