Volvo Penta D49A MS - Cooling System D49 A;D65 A MS KC (1 Circuit)

63
Maintenance: Freshwater system
Cooling system D49A/D65A MS KC (1 circuit)
The engine cooling water is cooled by, e.g, a box cooler, a grid cooler, or any other external heat exchanger. The
same coolant (fresh water) is cooling the complete engine.
1. Freshwater inlet
2. Freshwater pump
3. Lubrication oil cooler
4. Engine
5. Charge air cooler
6. Thermostat valve
7. Freshwater outlet
1.
2.
3.
4.
5.
3.
4.
6.
6.
7.
Freshwater drain points (D)
D
D
