Volvo Penta TAD1643VE User Manual

Engine Oil, Change
WARNING!
Hot oil and hot surfaces can cause burns.
Oil changes must be done when the engine is hot.
1 Connect the drain hose to the oil drain pump and
check that no leakage can occur.
2 Pump the oil out (or remove the bottom drain plug
and drain the oil).
Collect all the old oil and old filters, and hand them
to a re-cycling station for destruction.
3 Remove the drain hose (or install the bottom drain
plug).
4 Fill with engine oil.
For change volume, please refer to Technical
Data, page 92.
Maintenance
47711296 01-2019 © AB VOLVO PENTA 71

Volvo Penta TAD1643VE Specifications

General

Engine Model	TAD1643VE
Number of Cylinders	6
Compression Ratio	17.5:1
Fuel System	Common rail
Cooling System	Liquid-cooled
Displacement	16.1 liters
Bore	144 mm
Stroke	165 mm
Aspiration	Turbocharged, aftercooled
Emissions Compliance	EU Stage V
Engine Type	In-line 6-cylinder, 4-stroke diesel engine with direct injection
