Service and maintenance
Electrical system 127
Light bulb, replacing
1 Place the machine in service position, see page 89.
2 Open the engine hood.
3 Loosen rubber boot over the electrical terminals.
NOTE! When installing, make sure that the draining tube on
the rubber boot points downwards.
4 Disconnect the cable terminal from the light bulb.
5 Undo the locking clamp.
6 Replace the light bulb (70 Watt, socket H1).
NOTE! Do not touch the glass bulb on the new light bulb with
your fingers.
