Specifications
186 Steering/hydraulic system, specifications
Steering/hydraulic system, specifications
Tipping system
Full Suspension
Type of steering Hydro-mechanical articulated steering
Steering lock 2 × 45°
Number of steering wheel revolutions 3.4 revolutions
Pressure, max. 25 MPa (3626 psi)
A35E/A35E FS A40E/A40E FS
Make Volvo Volvo
Number of 2 pcs 2 pcs
Type Double-acting Double-acting
Tipping time 12 seconds 12 seconds
Lowering time 10 seconds 10 seconds
Tipping angle 70° 72°
A35E FS A40E FS
Number of cylinders 6 6
Cylinder bore, front axle 115 mm (4.45 in) 115 mm (4.45 in)
Cylinder bore, rear axles 150 mm (5.91 in) 150 mm (5.91 in)
Piston rod diameter, front axle 90 mm (3.54 in) 90 mm (3.54 in)
Piston rod diameter, rear axles 110 mm (4.33 in) 110 mm (4.33 in)
Stroke, front axle 230 mm (9.10
in) 230 mm (9.10 in)
Stroke, rear axles 230 mm (9.10 in) 230 mm (9.10 in)
Number of accumulators, front axle 2 2
Number of accumulators, rear axles 4 4
