Instrument panels
Right instrument panel 27
7 Hazard flashers
NOTE! Must only be used if the machine has to be stopped in
a way which constitutes a danger to other road users.
Upper end of switch pressed in = hazard flashers turned off
Lower end of switch pressed in = hazard flashers switched on
8 Rotating warning beacon (optional equipment)
Upper end of switch pressed in = rotating warning beacon
switched off
Lower end of switch pressed in = rotating warning beacon
switched on
9 Electrically heated rear view mirrors
(optional equipment)
Upper end of switch pressed in = heating switched off
Lower end of switch pressed in = heating switched on
10 Electrically heated seat (optional equipment)
Upper end of switch pressed in = heating switched off
Lower end of switch pressed in = heating switched on
11 Raised engine speed (optional equipment)
Upper end of switch pressed in = raised engine speed turned off
Lower end of switch pressed in = raised engine speed switched on
The operating speed control function will be engaged provided that
the following conditions are met:
– The function operating speed is activated from the service
display unit or VCADS Pro.
– No gear engaged (transmission in neutral).
– Lower end of switch pressed in.
12 Unassigned
13 FS-system
Upper end of switch pressed in = system operating position /
normal position
Lower end of switch pressed in = system in bottom position
A9002800
A9002900
A9002400
A9002300
A9002700
r/min
