Operating instructions
Transporting the machine 79
Lifting machine
The lifting tool is optional equipment to be used for lifting the
machine. They are intended for a machine weight of max.
33500 kg (A35E/A35E FS) / 39000 kg (A40E/A40E FS).
IMPORTANT! If the machine is equipped with FS-system, it
must be lowered right down before lifting is carried out.
Lifting tool, (optional equipment)
Q It is important that correct lifting tools and nuts are used.
Q The combination of rim and tyres determines which tool and
nuts are to be used, see below.
Q It is important that the lifting tool is installed in a correct way.
Q The lifting tool should only be installed on the machine for when
lifting and transporting. Remove the tool after use.
Q The nuts, which belong to the lifting tool, should preferably be
stored on the tool, when they are not used.
Q The ordinary wheel nuts should not be stored on the tool when
the tool is installed on the machine.
Q The lifting tool is marked with two decals that state which tool
and nuts should be used in combination with a certain rim and
tyre. The part number is also stamped-in on the lifting tool itself.
Tightening torque for nuts for lifting tool, 200 Nm (148 lbf ft).
WARNING!
Never remain under the machine when it is suspended in
the air.
WARNING!
Do not lift the machine using the eyes on the dump body.
WARNING!
The lifting tool must only be installed together with the
special nuts supplied together with the tool, otherwise the
tool may loosen causing serious damage. When removing
the tool, the ordinary wheel nuts must be reinstalled.
Lifting tool Nut
Part No. 15011655 Part No. 11193630
