OPERATION, ROOF
PREPARATIONS
• No objects on parcel shelf, roof or boot lid.
• 2 m clearance above and 0.2 m behind.
• Level ground.
• Outside temperature above –10 ˚C.
• Closed cargo separator and boot lid.
• Pay attention that no individual is close to
the roof's moving parts during its operation.
The side windows lower several centimetres
when the roof is operated. They then return
automatically.
CARGO SEPARATOR
OPERATION
1. The car must be stationary.
2. The engine must be running at idling speed.
3. Depress the brake pedal.
4. Press and hold button (A) or (B) until a signal
sounds and the message ROOF CLOSED/
ROOF OPEN is shown in the display.
5. Release the button.
The cargo separator limits the cargo area to
make space for the folding roof.
1.
Raise the cargo separator during loading.
2.
Fold down the cargo separator fully until
locked (3) before lowering the roof (see
the label on the cargo separator).
Raise/lower the lowered roof to facilitate
loading.
1.
Hold in the button until the roof is raised.
2.
Raise the cargo separator, load, and then
fold it down fully.
3.
Hold in the button until the roof is lowered.
