Volvo D12D - Page 15

Figure 6
12. Clean the unit injectors' copper sleeves with a brush on an extension.
Figure 7
1.
2.
3.
Extension
Brush
Protective sleeve
13. Check that all adapters have O-rings and seal against the copper sleeve. Install adapters 9998248 in the unit
injectors' place in the cylinder head.
