fuse for respective component.
4. Remove the three screws (3) that disconnect the clamps from the E-ECU.
5. Unplug the connectors EA and EB from the E-ECU.
6. Remove th screws (4) (6 pcs. ) that hold the cooler (3).
7. Remove the screws (5) (4 pcs.) that hold the E-ECU.
8. Carefully move aside the cooler and remove the E-ECU.
NOTE!
Work carefully so that hoses for the cooler are not damaged.
Mounting E–ECU
9. Lift in the E-ECU inside of the cooler.
10. Install the screws (5) (4 pcs.) that hold the E-ECU against the engine block.
11. Install the screws (4) (6 pcs.) that hold the cooler against the E-ECU.
12. Plug in the connectors EA and EB for the E-ECU.
13. Install the screws (3 pcs.) that hold the clamps against the E-ECU.
14. Close the engine hood.
NOTE!
When changing pre-programmed ECU, return to step 3.
200 E-ECU, MID 128, changing pre-programmed ECU
15. Finish VCADS Pro operation 28423-3 MID 128 ECU, programming.
