Volvo D13 - Page 27

VP70 - VP Status
Identifier PGN PDU format
(dec)
PDU spe-
cific (dec)
Data length Priority Description Update
period
Tx = transmit
Rx = receive
0x0CFF4611 65350 255 70 8 bytes 3 Engine control sta-
tus.
Rx 20ms
NOTICE! All unused signals must be set to ‘Not available’.
All unused bits in the messages used must be set to 1.
Frame Name / Signal name
Start request
Start position: 1.1
Length: 2 bits
Factor: 1
Offset: 0
0 = Inactive
1 = Active
2 = Error indication
3 = Not available
Stop request
Start position: 1.3
Length: 2 bits
Factor: 1
Offset: 0
0 = Inactive
1 = Active
2 = Error indication
3 = Not available
Governor mode select
Start position: 1.5
Length: 2 bits
Factor: 1
Offset: 0
0 = Engine speed mode request
1 = Torque mode request
2 = Error indication
3 = Not available
Idle speed select
Start position: 1.7
Length: 2 bits
Factor: 1
Offset: 0
0 = Normal running speed request
1 = Idle speed request
2 = Error indication
3 = Not available
Frequency select
Start position: 2.1
Length: 2 bits
Factor: 1
Offset: 0
0 = Primary engine speed request (1500rpm)
1 = Secondary engine speed request (1800rpm)
2 = Error indication
3 = Not available
Note: Only used on dual speed Genset engines.
Preheat request
Start position: 2.5
Length: 2 bits
Factor: 1
Offset: 0
0 = Inactive
1 = Active
2 = Error indication
3 = Not available
Engine restored operation
Start position: 2.7
Length: 2 bits
Factor: 1
Offset: 0
0 = Inactive
1 = Active
2 = Error indication
3 = Not available
Communication, J1939 Backbone 1 (BB1) - EMS
47706587 05-2015 © AB VOLVO PENTA 25
