Volvo EW180E - Page 103

C
Connection ports on dipper arm front left and right
1 Grab piping, left
Position for EWR150E, EW160E, EWR170E
6 X3, right
2 X3, left 7 Grab piping, right
Position for EWR150E, EW160E, EWR170E
3 X1, left 8 Grab piping, right
Position for EW180E, EW220E
4 Grab piping, left
Position for EW180E, EW220E
9 X1, right
5 Slope piping, both connections left 10 Hammer return, just one right
For the hydraulic pressure/flow specifications and for the
connection port specifications, see
350
X1 and X3 direction can be changed, for more information, see
58 and the following chapters:
- X1 work tool / Change X1 direction
- X3 operation / Change X3 direction
