Volvo EW180E - Page 96

C
Control levers, description
The standard machine control pattern is S
SA
E
E (I
S
S
O
O
)
)
. With the
pattern changer (optional equipment) this can be changed to
BHL
, see below.
1
1
.
. L
e
e
f
f
t
t co
n
n
t
t
r
r
o
o
l
l l
e
e
v
ve
r
r w
i
i
t
t
h
h S
A
A
E
E (
I
I
S
S
O
O
)
)
This lever is used to swing the superstructure and operate the
dipper arm.
Combined movements are obtained if the control lever is moved
to positions between the ordinary positions. For example, moving
the lever to position 6, see below, results in dipper arm in and
superstructure swing to the left.
N Neutral (superstructure and dipper arm in neutral position)
1. Dipper arm out
2. Dipper arm out and swing superstructure right
3. Swing superstructure right
4. Dipper arm in and swing superstructure right
5. Dipper arm in
6. Dipper arm in and swing superstructure left
7. Swing superstructure left
8. Dipper arm out and swing superstructure left
S
w
w
i
i
n
n
g
g b
r
r
a
a
k
ke
Brake the swing movement by moving the control lever to the
neutral position.
V1193100
Left control lever
1 Dipper arm out
2 Dipper arm in
3 Swing superstructure left
4 Swing superstructure right
9
4
4
O
t
t
h
h
e
e
r
r co
n
n
t
t
r
r
o
o
l
l
s
s
C
o
o
n
n
t
t
r
r
o
o
l
l
s
s
