06 Starting and driving
143
Load on the roof
06
Fitting load carriers
– Make sure the load carrier is fitted in the
right direction (see the marking on the
decal under the cover).
– Fit the guide pins into the guide holes (1).
– Carefully lower the bracket on the other
side to the roof.
– Screw the knob up a bit.
– Press the knob against the roof bracket
and catch the hook in the roof bracket
under the roof rail.
– Screw the load carrier in place.
– Fit the guide pins of the other brackets
into the guide holes.
– Screw the load carrier in place.
– Check that the hook is properly secured in
the roof bracket.
– Tighten the knobs alternately until the car-
rier feels secure.
– Replace the cover.
– Check that the roof rack is properly se-
cured.
NOTE
Check the knobs regularly to see that they
are properly tightened.
