09 Maintenance and service
Lamps
09
``
* Option/accessory, for more information, see Introduction.
341
Main beam, Halogen
G021747
1. Detach the headlamp.
2. Remove the cover, see page 340
3. Detach the bulb by turning anticlockwise
and then pulling straight out
4. Unplug the connector from the bulb.
5. Replace the bulb and align it in the socket
and turn clockwise in order to secure it. It
can be secured in one position.
Reinstall the parts in reverse order.
Extra main beam, ABL headlamps*
G021748
1. Detach the headlamp.
2. Remove the cover, see page 340.
3. Detach the bulb by pressing the holder
downwards.
4. Unplug the connector from the bulb.
5. Fit the new bulb in the socket and snap it
in. It can only be secured in one position.
Reinstall the parts in reverse order.
Position/parking lamps
G021749
1. Detach the headlamp.
2. Remove the cover, see page 340.
3. For better access, detach the main beam
bulb first.
4. Pull the cable in order to withdraw the bulb
holder.
5. Remove the blown bulb and fit a new one.
It can only be secured in one position.
6. Fit the bulb holder in the socket and press
until a clicking sound is heard.
Reinstall the parts in reverse order.
