09 Maintenance and service
Fuses
09
356
* Option/accessory, for more information, see Introduction.
Function A
- -
Headlamp control 5
- -
- -
- -
Internal relay coils 5
Auxiliary lamps* 20
Horn 15
Relay coil in main relay for
engine management system;
Engine control module (5, 6-cyl.
petrol)
10
Transmission control module 15
Solenoid clutch A/C (not 5-cyl.
diesel); Coolant pump (5-cyl.
diesel Start/Stop)
15
Function A
Relay coil in relay for solenoid
clutch A/C (not 5-cyl. diesel);
Relay coil in relay for coolant
pump (5-cyl. diesel Start/Stop);
Relay coils in central electrical
unit in engine compartment cold
zone (Start/Stop)
5
Start relay
A
30
Ignition coils (4-cyl. petrol);
Glow control module (5-cyl. die-
sel)
10
Ignition coils (5, 6-cyl. petrol);
Capacitor (6-cyl.)
20
Engine control module (petrol) 10
Engine control module (diesel) 15
Function A
Valves (1.6 l petrol); Mass air
flow sensor (1.6 l petrol)
Mass air flow sensor (D4162T);
Control valve, fuel flow
(D4162T)
10
Mass air flow sensor (5-cyl. die-
sel, 6-cyl.); Control valves (5-
cyl. diesel); Injectors (5, 6-cyl.
petrol); Engine control module
(5-cyl. petrol, 6-cyl.)
15
Solenoid clutch A/C (5, 6-cyl.);
Valves, Engine control module
(6-cyl.) Solenoids (6-cyl. without
turbo); Actuator motors, intake
manifold (6-cyl. without turbo);
Mass air flow sensor (4-cyl. 2.0
l petrol, 5-cyl. petrol); Oil level
sensor (5-cyl. diesel)
Coolant pump (D4162T)
10
Lambda-sonds (4-cyl. petrol);
Lambda-sond (diesel); Control
module, radiator roller cover
(manual 5-cyl. 2.0 l diesel)
10
EVAP valve (5, 6-cyl. petrol);
Lambda-sonds (5, 6-cyl. petrol)
15
