09 Maintenance and service
Replacing bulbs
09
``
235
Fitting the lamp housing
1. Plug in the connector and refit the lamp
housing and locking pin. Check that the pin
is correctly inserted.
2. Check the lighting.
The lamp housing must be plugged in and
secured in place before the lighting is switched
on or the remote control key inserted into the
ignition switch.
Dipped beam
G019131
Removing the cover and bulb
1. Undo the whole lamp housing, see
page 234.
2. Bend aside the catches and remove the
cover.
3. Unplug the connector from the bulb.
4. Release the spring clip securing the bulb.
Press it in/down.
5. Pull out the bulb.
G019133
Fitting a new bulb
1. Fit the new bulb. It can only fit in one posi-
tion.
2. Press the spring clip in/up and then slightly
to the right in order to snap it into position.
3. Press the connector back on.
4. Refit the plastic cover.
5. Refit the lamp housing, see page 234.
Main beam, Halogen
G019136
The illustration shows a halogen bulb.
1. Undo the whole lamp housing, see
page 234.
2. Undo the cover, located above the lamp
housing, by turning it anticlockwise.
3. Left-hand headlamp:
Turn the bulb holder anticlockwise.
Right-hand headlamp:
Turn the bulb holder clockwise.
