09 Maintenance and service
Replacing bulbs
09
236
* Option/accessory, for more information, see Introduction.
4. Withdraw the bulb holder and change the
bulb.
5. Refit the bulb holder. It can only be refitted
in one position.
6. Refit the cover, located above the lamp
housing, by turning it clockwise.
7. Refit the lamp housing, see page 234.
Position/parking lamps
G019145
1. Undo the lamp housing, see page 234.
2. Undo the cover, located above the lamp
housing, by turning it anticlockwise.
3. Withdraw the bulb holder and change the
bulb.
4. Press the bulb holder back on. A "click" is
heard when the bulb holder is fitted cor-
rectly.
5. Refit the cover, located above the lamp
housing, by turning it clockwise.
6. Refit the lamp housing, see page 234.
NOTE
ABL headlamps* have a position lamp (LED)
that cannot be replaced.
Direction indicators
G019150
1. Undo the lamp housing, see page 234.
2. Twist the bulb holder anticlockwise and
remove it.
3. To remove the bulb from the bulb holder,
press the bulb in and turn it anticlockwise.
4. Fit a new bulb and refit the bulb holder into
the lamp housing.
5. Refit the lamp housing, see page 234.
