6) TONE CONTROL: EQ in feedback path of echo, turn clockwise for brighter repeats
and counter clockwise for darker
7) REPEATS CONTROL: Feedback amount for delay lines, from 0% for a single repeat
up to 110% for self oscillation and distortion.
8) DEPTH CONTROL: Depth of pitch modulation on echo signal. At 12 oʼclock, there is
no pitch modulation. Counter clockwise for sine wave modulation and clockwise for
random modulation.
9) RATE CONTROL: Speed of pitch modulation on echo signal.
10) MIX CONTROL: Balance of dry and wet signals.
11) MIDI INPUT: Type B, 3.5mm TRS input jack
12) TIME CONTROL: 9 discrete max echo times ranging from 85 ms to 22 sec. No pitch
modulation artifacts when adjusted.
13) ECHO STYLES: Reroutes the echo feedback paths.
● DUAL STEREO: two independent echos that can be used in stereo or stacked in
mono.
● PING PONG: Echoʼs feedback into each other
● MONO: Mono echo with feedback path routed to Right input and output jacks
for external processing.
14) TRIG: footswitch for tap tempo or toggles infinite mode, depending on “TRIG
FUNCTION” selection.
15) LEFT AND RIGHT SLIDERS: time control for delays that scale the delay time from
x1 to x0.05, press “SYNC” to lock both delays to the le slider.
16) BYPASS: footswitch to toggle effect on/off, buffered bypass
