Voodoo Lab Pedal Switcher User Manual

The only completely transparent way to switch both instrument and line level signals (with no
audible distortion) is with relays. Pedal Switcher uses the finest gold contact relays sealed in
nitrogen.
PEDAL SWITCHER LOOPS
The basic function of a Pedal Switcher loop is to bring your effects in and out of the signal path
via true bypass, instant access switches.
LOOP ON LOOP OFF LOOP ON LOOP OFF
In this example, the Overdrive and Delay pedals are on. But, the Fuzz and Chorus pedals are
completely bypassed.
IN OUT
OD
IN OUT
FUZZ
IN OUT
CHORUS
IN OUT
DELAY
