Vortex B series User Manual

18
www.bluelinevacuum.com
Sr.
Name
Qty
Material
Sr.
Name
Qty
Material
1
end cover A
1
HT200
14
side cover
2
HT250
2
connecting base
for motor
1
HT200
15
end cover B
1
HT250
3
sealing seat
1
HT250
16
active gear
1
20CrM
n
Ti
4
sealing cover
1
HT200
17
drive gear
1
20CrM
n
Ti
5
shaft sleeve A
1
20CrM
n
Ti
18
bearing seat
A
2
HT200
6
shaft sleeve B
1
45#
19
bearing seat
B
2
HT200
7
gland cover
1
Q235-A.F
20
bearing cover
A
2
HT200
8
repair spare part
gasket
1
HT200
21
bearing cover
B
2
HT200
9
active rotor shaft
1
22
oil deflector
4
HT150
10
pump body
1
HT250
23
sealing ring
set
4
QT400
11
left frame
1
HT250
24
side cover
bushing
4
HT200
12
right frame
1
HT250
25
bearing C
1
HT150
13
drive rotor shaft
1
26
bearing D
3
HT150

Vortex B series Specifications

General

Brand	Vortex
Model	B series
Category	Water Pump
Language	English
