9.2 Vortex B series installation size (Unit: mm)
Model
A
A1
A2
A3
A4
A5
B
B1
B2
H
H1
H2
H3
H4
K
Vortex
250
752
560
223
178
343
-
294
240
184
288
28
118
38
175
14
Vortex
500
900
640
252
195
385
-
400
320
260
365
28
145
40
225
20
Vortex
1000
1074
800
332
275
465
-
400
320
260
403
30
158
53
243
20
Vortex
2000
1355
830
393
278
483
557
574
480
354
560
39
205
40
345
24
Vortex
9000
1690
1000
500
316
632
670
630
520
410
590
37
220
35
355
24
Model
D
D1
D2
E
d
d1
d2
F
N
N1
N2
W
Q
M
Vortex
250
80
125
145
4-M8
80
125
145
4-M8
80
125
145
192
4-M8
-
Vortex
500
100
145
170
4-M10
100
145
170
4-M10
100
145
170
245
4-M10
-
Vortex
1000
150
195
220
8-M10
150
195
220
8-M10
100
145
170
285
8-M10
-
Vortex
2000
200
250
275
8-M10
200
250
275
8-M10
200
250
275
375
8-M10
M20
Vortex
9000
250
310
335
12-M10
200
260
265
12-M10
200
260
285
425
12-M10
M20
