Speed adjustment
Danger! Danger of electrocution.
► Before working on the pump, disconnect
power supply and ensure that it cannot be
reconnected unintentionally (see g. 1).
► Check to make sure the power is turned off.
Warning! Hot surface on pump housing and
motor. Danger of burns!
► Avoid direct contact with pump housing and
motor.
 The speed is innitely variable.
Q [l / h]
H [mWS]
0 100 200 300 400 500 600 700
0,2
0,4
0,6
0,8
1,0
1,2
1,4
2
4
6
8
10
12
14
800 900
n = 2000 - 3000 1/min
n = 2000 - 3000 1/min
BWO 155 V
BWO 155 R
[kPa]
