Pump Servicing
Easy Start Removal
1. Remove the easy start plug and inspect the
o-ring for damage or wear and replace if nec-
essary.
2. Remove the ball and spring then clean them
and the barb of calcium build-up.
3. Using a coarse wood screw, insert it into the
seat and twist it until the threads catch in the
small hole at the bottom of the seat. When the
treads catch you will be able to pull the seat
out. Inspect the o-ring for damage or wear and
replace if necessary.
Easy Start Installation
1. Insert the seat then use something long and
skinny to push it fully into position inside the
pump head.
2. Place the spring in next making sure that it is
inserted inside the seat.
3. Insert the ball on top of the spring.
4. Install the easy start plug and torque it down
to 221 ft. lbs.
Unloader Valve Removal
1. Remove unloader from the head.
2. Using a hooked pick pull pull out the seat.
It may be stuck tight so you may need to pull
from multiple angles to work it out. Inspect
seat o-ring for damage or wear and replace if
necessary.
