The versatile magnification of the Diamondback spotting scope allows for observing a
wide field of view at a lower power and zooming in on distant details at a higher power.
Adjust the magnification
Change the magnification of your spotting scope
by simply turning the magnification adjustment
ring.
• Increase the magnification by turning the
adjustment ring in a clockwise direction.
• Decrease the magnification by turning the
adjustment ring in a counter-clockwise direction.
Caution: Never look directly into the sun (or any other intense light) with your Diamondback
spotting scope. This could cause damage to the retina and cornea of your eyes to the point of
causing blindness.
Adjust the focus
After changing the magnification, some refocusing is usually required. Turn the focus dial
to adjust the fine focus. This fine focusing does more than allow you to see critical details.
A well-focused image
also ensures fatigue-free
viewing.
Rotate the Focus Dial

Vortex Diamondback Specifications

General

Exit pupil	3.6 mm
Eye relief	18 mm
Prism type	-
Waterproof	Yes
Lens coating	Fully Multi Coated (FMC)
Magnification	8 x
Product color	Black, Green
Objective diameter	28 mm
Field of view (at 1000 m)	101.19 m
Interpupillary distance (max)	74 mm
Interpupillary distance (min)	55 mm

Weight and Dimensions

Depth	- mm
Width	116.84 mm
Height	111.76 mm
Weight	396.89 g
