Vortex PRO - Attaching and Removing the Leveling Head

PRO TRIPOD LEVELING HEAD
2 3
1/4"-20 THREAD
3/8"-16 THREAD
BUBBLE LEVEL
KNURLED
CONTROL RING
Attaching/Removing the Leveling Head
The Pro Leveling Head is compatible with the High
Country
™
II, Summit
™
Carbon, and Ridgeview
™
Carbon
Vortex
®
tripods, or any tripod with a 3/8"-16 thread.
Note: You can also swap the 3/8”-16 threaded insert for a 1/4”-
20 threaded insert on the bottom of the leveling head for use
with any tripod with 1/4”-20 thread.
To attach the leveling head to the tripod:
1. Remove the pan head from the tripod by turning the
head counter-clockwise.
2. Install the leveling head by turning the head
clockwise.
