62
Aplicaţii tipice
Fig. 1-2.
Instalare
Fig. 3 ÷ 19.
Funcționare
Cele două viteze ale aspiratorului prin comutatorul de la distanță în 2 poziții. Consultați diagramele de
conectare pentru conectarea comutatorului.
Scheme pentru conectarea electrică
Fig. 18 ÷ 19.
Reglare timer
Fig. 20 ÷ 24.
Întreţinere și curăţare
Fig. 25 ÷ 27.
Specificații tehnice
ROMÂNĂ
50 Hz
PRODUS V Hz
Putere
(Max/
Min)
[W]
Curent
de aer
(Max/
Min)
[m
3
/h]
Presiune
(Max/
Min)
[mmH
2
O]
RPM
(Max/
Min)
[nr.
rotații/1’]
LpA [db(A)] 3m
-IRADIAT-
(Max/ Min Vel.)
CLASĂ DE
IZOLARE
TEMPERATUR
MAX CAMER [°C]
LINEO 100
LINEO 100 T
220-240 50
23/
20
255/
180
16,5/
13
2030/
1520
39,4/
30,7
II 60
LINEO 100 Q
LINEO 100 Q T
220-240 50
15/
12/
200/
155/
7,5/
6,5/
2450/
1860/
37,9/
29,4/
II 60
LINEO 125
LINEO 125 T
220-240 50
33/
25/
365/
250/
17/
13/
2140/
1570/
43/
33,9/
II 60
LINEO 150
LINEO 150 T
220-240 50
58/
40/
550/
385/
27/
21/
2100/
1580/
50,5/
41,4/
II 60
LINEO 160
LINEO 160 T
220-240 50
58/
40/
550/
385/
27/
21/
2100/
1580/
50,8/
41,7/
II 60
LINEO 200 Q
LINEO 200 Q T
220-240 50
75/
45/
950/
700/
29/
13/
2740/
1780/
49/
39,6/
II 60
LINEO 250 Q
LINEO 250 Q T
220-240 50
110/
85
990/
720
53/
34
2550/
1850
56,2/
49,1
II 60
