95
32
QE 100/60/35 LL
A
B
Main terminal block
C
100m3/h switch
123LN
A
Room light
D
E
E
F
L
N
35m3/h switch
C
D
(*) Presence of voltage. Connect room light only by means of two-pole switch.
(*) (*)
B
Main bipolar switchF
60m3/h switch
(*)
