04. Explanation production label
Caption of production label (FIG. I):
1.
Serial number (manufacturing date)
15.
Connection (5)
29.
Thermal protection (6)
2.
Article number customer
16.
Power (kW or HP) (7)
30.
Speed (RPM)
3. Article number VV 17. Nominal current (A) 31. Max. ambient temperature
4.
Description customer
18.
Condenser (µF/V)
32.
TEAO (Totally Enclosed Air Over)
5.
Fan type
19.
Controllability (3)
33.
Approval
6.
Product line (4)
20.
Winding diagram
34.
Name of manufacturer
7.
Manufacturing year
21.
cos phi
35.
Address of manufacturer
8.
Weight (kg)
22.
Service factor
36.
Country of manufacturer
9.
Connection diagram
23.
IP-class
37.
Brandname / text
10.
Brand name
24.
Insulation class
38.
Work order
11.
Bar code
25.
Static pressure (0 Pa)
39.
Tester code
12. Number of phases 26. Air volume at 0 Pa (m
3
/h) 40. Name of manufacturer 1/2
13.
Voltage (V)
27.
Static pressure (x Pa)
41.
Name of manufacturer 2/2
14.
Frequency (Hz)
28.
Air volume at x Pa (m
3
/h)
42.
Country of manufacturer
(3)
E = controlable electronically (electronic voltage regulation by a TRIAC/SRC), T = controllable by transformer (electronic
voltage regulation by a transformer), F = frequence controllable (controllable by a frequence controller). A frequence
controller in combination with a single phase motor is possible.
(4)
E = EMI, Q = Q-line Multifan, MF = Mf-Flex
(5)
e.g.: (230/400V = U1/U2) D = Triangle connection for U1, Y = Star connection for U2
(6)
Thermal protection (NC) (for single phase: 250V 2.5A cosφ =1 / for 3-phase: 250V 10A cosφ =1)
(7)
Power input for fans, Power input for motors in kW or HP
05. Assembly/mounting/installation
• Mounting, electric connection and start-up may be executed by qualified personnel only
(according to EN 50110-1 and EN 1010-1).
• It is the installer's responsibility that the installation and safety instructions are in accordance
with current standards and regulations (according to EN-ISO 13857 and EN ISO 12100-1).
• Every fan has to be grounded according to the current standard EN 50178.
• Do not use the fan as part of a construction.
• In case a moving part of the fan (the impeller) is below 2.7m (measured from the floor to the
lowest point of the fan), a protective wire guard (according to EN-ISO 13857) is mandatory. See
also FIG. VI.
• Remove the red condense plug, mounted at the lowest point of the motor. Keep the condense
plug in a safe place, for it is necessary to use it during cleaning and maintenance work. See also
FIG. VI.
• Vostermans Ventilation B.V. has an (optional) fastening set (article number ‘BGMFFLEXST’) in
her delivery program. Inquire about the possibilities.
CAUTION: In case of speed regulation, the fan may vibrate when
incorrectly mounted/installed. Check this before completing the
installation.
CAUTION: The fan must ALWAYS be built-in or mounted in a stable
way before being taken into operation!
