Vox AC15CH Service Manual

530000001922 AC INLET 3PINS 250V 10A CASING 28 28 26 AC INLET 1 1 1
530000002127 TRANS AUDIO 173.2V/10.4- CASING 45 45 41 AUDIO TR 1 1 1
530000002123 WOOD BAFFLE 555.6X381X20 CASING 1 BAFFLE 1 0 0
530000002136 REVERB MODULE REVERB TANK BS3EB 3C1B CASING 14 11 REVERB 101
530000002124 WOODEN FRAME 602*427*262 CASING 3 CABINET 1 0 0
530000002140 WOOD COVER LOWER 560X100/X18 CASING 12 1 0 0
530000002141 WOOD COVER UPPER 580X272X18 CASING 23 1 0 0
530000002039 WOOD BAFFLE 650X479.5X20 CASING 0 1 0
530000002040 WOODEN FRAME 697*262*526 CASING 0 1 0
530000002041 WOOD UPPER COVER CASING 0 1 0
530000002042 WOOD LOWER COVER MDF CASING 0 1 0
530000003421 WOOD CAB 697X260X239 MDF T18 CASING 1 0 0 1
530000002118 REVERB MODULE REVERB TANK CASING 13 0 1 0
530000002078 RUBBER PAD REVERB CASING 9 0 2 0
530000002100 SWITCH TOGGLE DPDT 250V CASING 29 29 21 2 2 2
530000002076 HANDLE-TOP 187X25.8X15.8 CASING 49 44 10 1 3 1
530000002095 SCREW MACH O-CS 4X25 CR CASING 24 24 CABINET 14 14 0
530000001918 SCREW TA-C1 O-CS 4X32 CR LCS CASING 11 11 CABINET 8 8 0
530000003422
SCREW MACH M6X35MM BLK CASING
14 444
530000003423
SCREW MACHINE OVAL-CS M4 X28 CASING
60020
530000003424
SCREW TA-C1 O-CS M4X35 CASING
7 005
530000002074 PLASTIC BUSHING CASING cable 1 1 1
530000002112 CABLE SPEAKER 2P L=500 CASING CABLE 2P 1 1 1
530000002072 GASKET PE 600*10*1.0MM CASING chassis 1 1 1
530000002079 CLOTH VINYL BROWN CASING CLOTH 1 1 1
530000001926 CORNER PLASTIC CASING 4 4 CORNER 4 4 4
530000002057 JACK RCA 1P WHITE CASING REVERB 1 1 1
530000002058 JACK RCA 1P RED CASING REVERB 1 1 1
530000002134 GRILLE-REAR 510X98X1 CASING GRILLE 1 1 1
530000002069 SPECIAL WASHER 18.9X18X CASING 44 44 19 INPUT 3 3 3
530000000205 KNOB ABS (CHIKEN HEAD) CASING KNOB 9 9 9
530000003425
KNOB MINI BLACK CASING
2447-9702+0 0 0 1
530000003426
LABEL FUNCTION 55X41 PGD CASING
3001-5190+0 0 0 1
530000003427
CHASSIS ATT CASING
1409-0101+0 0 0 1
530000002099 SWITCH SLIDE SPDT 125V
CASING 16 16 Impedance Selector 1 1 1
530000003437
SWITCH SLIDE SPDT 125V
CASING 16 16 52 Impedance Selector 1 1 1
530000001933 LED HOLDER 8X14.6
CASING 35 35 LED HOLDER 1 1 1
530000003370
LED HOLDER D9.25X13.4 ME CASING
35 35 30 LED HOLDER 1 1 1
530000001932 LED CY 5.0X8.6X25 RD CASING 30 30 30 LED1 1 1 1
530000001874 LOGO 45X11 CASING 52 52 8 LOGO 1 1 1
530000002101 THERMISTOR NTC 10R 20% CASING Surge Guard 1 1 1
530000002107 WIRE-GND 1P #16 UL1015 CASING AC INLET GND 1 1 1
530000002075 SPACER REVERB CASING 13 13 12 REVERB 4 4 4
530000001925 RUBBER FOOT D32X16.5 CASING 2 2 rubber foot 4 4 0
530000003176
RUBBER FOOT D30X25.5 COM NT15H CASING
2 rubber foot 0 0 4
530000002074 PLASTIC BUSHING CASING transformer 1 1 1
530000002073 RUBBER SPACER ID5*OD20*4 CASING 57 57 TUBE 1 1 0
530000002077 RUBBER FOOT 14.5X14.5X1 CASING TUBE 1 1 0
530000002106 WIRE-CONN 1P #18 UL1672 CASING TX OUT 1 1 1
530000002071 SHIELD TUBE 35X27X55 AL CASING 17 17 55 V1 T 1 1 1
530000002080 VALVE COMPACTRON 12AX7B CASING 9 9 58 V1 T, V2 T, V3 T 3 3 3
530000002081 VACUUM TUBE COMPACTRON EL84 CASING 10 10 59 V4 T, V5 T 2 2 2
530000002067 CLIP TUBE 34X27X68 METAL CASING 19 19 57 VALVE 2 2 2
530000002068 CLIP-TUBE SECC T=1 WHT CASING 18 18 56 VALVE 2 2 2
530000002046 VENT-LARGE PP BLK 94V0 CASING 51 51 3 2 3 9
530000002047 AC INLET WHITE CASING AC INLET WHITE 1 1 1
530000002125 CHASSIS-MAIN AC15C1(EU/UK/AUS) CASING 36 36 16 CHASSIS(EU/UK/AUS)
530000002126 CHASSIS-MAIN AC15C1(JP/US)
CASING 36 36 CHASSIS(JP/US)
530000003428 CHASSIS-MAIN AC15C1(JP/US) CASING 36 36 16 CHASSIS(JP/US)
530000003429 PANEL TOP 560X75 PC+EC53 CASING 35 0 0 1
530000002128 TRANSFORMER PWR 230V 43 43 38 POWER TR(EU/UA)
530000002129 TRANSFORMER PWR 100V 43 43 38 POWER TR(JP)
530000002130 TRANSFORMER PWR 120V 43 43 38 POWER TR(US)
530000002131 TRANSFORMER PWR 240V 43 43 38 POWER TR(AUS)
1
111
11CASING
Transformer
