SPEAKER OUT jacks, OUTPUT SELECT switch

Connect your speaker cabinet(s) to the SPEAKER OUT jack(s). Refer to the table

below, and set the OUTPUT SELECT switch to the appropriate setting for the cab-

inet(s) you’re using.

NOTE: Only the AD100VTH has these jacks and this switch.

Important: Any combination of connections other than described above may damage

your speakers or amp.

• Don’t connect a speaker cabinet that’s rated for less than 100 watts of input

power. The speakers may be damaged if you do so.

•You must use a speaker cable to connect your speaker cabinet. Don’t use

the shielded cable typically used to connect a guitar to an amp.

•You must connect cables with the power turned off. Connecting or discon-

necting cables with the power on may damage the amp.

PRESENCE control

Adjust the presence according to the tone of the speaker cabinet(s) you’ve con-

nected.

NOTE: The presence setting is not programmed.

NOTE: Only the AD100VTH has this knob.

Speaker cabinet

impedance and number

OUTPUT SELECT

switch (

AD100VTH)

Maximum output

(impedance)

8Ω x 2

Serie 50 W (16Ω)

16Ω x 1

Parall 50 W (16Ω)

8Ω x 1 + 4Ω x 1

Serie 75 W(12Ω)

4Ω x 2

Serie 100W (8Ω)

8Ω x 1

Parall 100W (8Ω)

16Ω x 2

Parall 100W (8Ω)
