VALVE
4.1 Valve window
ToneLab contains a 12AX7 (ECC83) valve (vacuum tube).
The valve is a key part of the Valve Reactor power amp.
NOTE: The valve window may break if it is subjected to impact. Be particularly
careful not to let it be struck directly, since this may also break the valve itself. If the
valve window is broken, have it repaired immediately, since the valve itself may
break or other damage may occur if this is not fixed.
INPUT/PHONES (The Front Panel)
5.1 INPUT Jack
Connect your guitar to this jack.
5.2 PHONE Jack (stereo)
Connect your headphones here. The rear panel LEVEL knob adjusts the head-
phone volume.
